NeoVolta NV16KAC Hybrid Inverter
The NV16KAC is a 16,000W hybrid inverter built for whole-home solar and storage installations. With 200A passthrough, 24kW of DC PV input across four independent MPPTs, and support for both split-phase and three-phase configurations, it covers a wide range of residential and light commercial applications — including complex or high-demand load profiles.
Designed and engineered in California, the NV16KAC runs on-grid or off-grid, handles 100% unbalanced loads, and includes a third multi-purpose AC terminal for generator input, AC-coupled solar, or load-shed functionality. Efficiency is rated at 96.5%, with a 15-year warranty and IP65/NEMA 3R weatherproofing.
Key Specs:
-
Continuous AC Output: 16,000W (on-grid and backup)
-
DC PV Input: 24,000W max / 500V max Voc
-
MPPT Channels: 4 independent MPPTs, 120–430V range
-
AC Passthrough: 200A continuous
-
Battery Compatibility: LiFePO4, 40–58V, up to 260/280A charge/discharge
-
Backup Surge: 20kW @ 10s / LRA 167A
-
Operating Temp: -13°F to 140°F (-25°C to 60°C)
-
Certifications: UL1741 (SA/SB), UL1699B, CEC listed, SGIP approved, IEEE 1547, CA Rule 21
-
Dimensions: 19.5" × 35.4" × 10.2" | Weight: 123 lbs
-
Communication: RS485, WiFi; optional 4G
Includes: Generator auto-start support (2-wire), smart load management, arc fault protection, DC/AC Type II surge protection, and Solarman Business monitoring compatibility.
